Havis Docking Station for Getac F110 Tablet

Part Numbers 543391800501/2

• Compatible with new & legacy Getac F110 tablets
• Advanced alignment for easy docking
• One-handed docking & undocking
• Lightweight & compact design
• Rounded edges for comfort & safety
• Getac certified Electronics
• Optional Triple pass-through antenna connections (SMA type)
• Integrated VESA 75 mounting pattern
• Lock and key supplied for peace of mind theft deterrence
• Made in the USA

Havis Vehicle Docking Stations

Part Number	Description	Price*
543391800501	Havis DS-GTC-221 Docking Station without Vehicle Charger for F110	£509.00
543391800502	Havis DS-GTC-221-3 Docking Station with Tri Pass-through, without Vehicle Charger for F110	£635.00

*Please note all prices shown are exclusive of VAT







Havis Docking Station Specifications

Compatible computer	Getac F110 tablet
Dimensions	10.28"H (26.11 cm) x 13.02"W (33.07 cm) x 3.18"D (8.07 cm)
Certifications	Vibration Testing: MIL-STD 810H 514.8, crash test: SAE J1455 30mph Crash Testing, cycle test: latch handle & docking connectors mechanism 30,000 cycles, CE, RoHS
Connectivity includes	serial: DB9 (9-Pin) connection (2), USB: fully-powered USB 2.0 (3), fully-powered USB 3.0 (1), Ethernet: RJ45 Ethernet (1), video: VGA (1), HDMI (1), speaker & mic: (1 each), input voltage: 19V DC, Optional triple pass-through antenna connectors (SMA type)
Product weight	2.75 lbs (1.25 kg)
Gross weight	3.5 lbs (DS-GTC-221), 4.2 lbs (DS-GTC-221-3)



These Havis docking stations are compatible with the following Getac models:

Getac F110 Tablet G5
Getac F110 Tablet G6
Getac F110 Tablet G7

Gamber-Johnson Docking Station for Getac F110 Tablet

Engineered for the demanding work environments in utility, public safety, and material handling

Designed for the Getac F110 fully rugged tablet, the Gamber-Johnson F110 docking station helps field service professionals meet the demands of extreme working environments.

Full port replication (dock) provides the peripheral connections needed to support a mobile office environment and the fast dock/release saves time when taking the tablet out for your work. This docking station accommodates the magnetic strip reader and hand strap. The keyed-lock provides added security and theft deterrence.

• Designed for the Getac F110 tablet computer
• Getac certified electronics
• Docking station accommodates the tablet’s mag strip reader and rotating hand strap
• Access to all tablet control buttons and ports while the tablet is docked
• Downward-facing I/O ports; integrated cable strain relief and cable management system
• Floating docking connector for reliable connectivity in the most rugged environments
• One-hand docking and release for efficient use all day long
• Keyed lock for theft deterrence
• Rounded edges to enhance personal safety
• Gamber-Johnson rugged construction and reliability
• Composite design for reduced weight and durability
• VESA 75 mounting pattern

Gamber-Johnson Docking Stations

Part Number	Description	Price*
543391800003	Gamber-Johnson 7160-1642-00 Vehicle Cradle without Vehicle Charger for F110	£283.00
543391800004	Gamber-Johnson 7160-1642-03 Vehicle Cradle with Tri Pass-through, without Vehicle Charger for F110	£328.00
543391800001	Gamber-Johnson 7160-1584-00 Vehicle Dock without Vehicle Charger for F110	£575.00
543391800002	Gamber-Johnson 7160-1584-03 Vehicle Dock with Tri Pass-through, without Vehicle Charger for F110	£618.00
543391800013	Gamber-Johnson 7160-1584-40 Vehicle Dock with Powered RS232 (Serial), without Vehicle Charger for F110	£575.00
543391800014	Gamber-Johnson 7160-1584-43 Vehicle Dock with Powered RS232 (Serial) and Tri Pass-through, without Vehicle Charger for F110	£618.00

*Please note all prices shown are exclusive of VAT







Gamber-Johnson Docking Station Specifications

Certifications and Testing	Getac Certified
	Vibration Tested: MIL-STD 810H Operational/Non-Operational
	Shock Crash Hazard: SAE J1455; Mechanical Shock: 40G
	Cycle Test: Latch, Lock, and Docking Connector - 30,000 Cycles
	Environmental: Humidity, Thermal Shock; High/Low Temperature Operational & Storage
	FCC, CE, MKCA, RoHS Certified
Dimensions	Weight: 2.88 lbs (3.31 kg)
	Height: 13.33 in (33.86 cm)
	Width: 11.75 in (29.85 cm)
	Depth: 4.69 in (11.91 cm)
Port Replication	Getac Certified Electronics
	Serial: D-sub 9 Pin (2)
	VGA D-Sub 15 Pin (1)
	HDMI (1)
	USB 2.0 - 4 Pin (3)
	USB 3.0 - 9 Pin (1)
	Ethernet RJ45 (1)
	Speakers/Microphone (1 each)
	Power Input: 19 Vdc
	Antenna: TRI RF (SMA) (Optional)



These Gamber-Johnson docking stations are compatible with the following Getac models:

Getac F110 Tablet G1-5
Getac F110 Tablet G6
Getac F110 Tablet G7
