Gamber-Johnson Docking Station for Getac ZX10 Tablet
Engineered for the demanding work environments in material handling, manufacturing, and transportation
Designed for the Getac ZX10 fully rugged tablet, the Gamber-Johnson ZX10 docking station helps professionals in material handling and transportation complete their daily work challenges. Powered dual USB ports provide connections for scanners, printers, or other peripherals needed to support a mobile office environment and the fast dock/release saves time when taking the tablet out for your work.
This docking station accommodates the tablet’s card reader, extended battery, hand strap, stylus, barcode reader, and hard carry handle, allowing for uninterrupted productivity on the job. The keyed-lock provides added security and theft deterrence.
- Compatible with the Getac ZX10 tablet computer
- Getac certified electronics
- Docking station accommodates the tablet’s card reader, extended battery, hand strap, stylus, barcode reader, and hard carry handle
- Docking connector gasket provides additional water resistance and protection
- Access to all tablet control buttons and ports while the tablet is docked
- Downward-facing I/O ports; integrated cable strain relief and cable management system
- Floating docking connector for reliable connectivity in the most rugged environments
- One-hand docking and release for efficient use all day long
- Keyed lock for theft deterrence
- Gamber-Johnson rugged construction and reliability
- Composite design for reduced weight and durability
- VESA 75 mounting pattern
| Part Number | Description | Price* |
| 543391900505 | Gamber-Johnson 7160-1676-00 Vehicle Cradle without Vehicle Charger for ZX10 | £265.00 |
| 543391900506 | Gamber-Johnson 7160-1676-03 Vehicle Cradle with Tri Pass-through, without Vehicle Charger for ZX10 | £311.00 |
| 543391900501 | Gamber-Johnson 7160-1675-00 Vehicle Dock without Vehicle Charger for ZX10 | £429.00 |
| 543391900502 | Gamber-Johnson 7160-1675-03 Vehicle Dock with Tri Pass-through, without Vehicle Charger for ZX10 | £501.00 |
*Please note all prices shown are exclusive of VAT
| Certifications and Testing | Getac Certified |
| RoHS, FCC, CE, E-Mark UKCA | |
| MIL-STD 810H vibration testing: Operational/Non-operational | |
| Shock crash hazard: SAE J1455; Mechanical Shock 40g | |
| Environmental: Thermal Shock, Humidity, High/Low Temperature - Storage/Operational | |
| EMI - Electromagnetic Interference | |
| Cycle Testing: Docking Connector, Latch and Locking mechanism - 30,000 cycles | |
| Dimensions | Weight: 2.6Ibs (1.18 kg) |
| Height: 9.89 in (25.12 cm) | |
| Width: 11.49 in (29.18 cm) | |
| Depth: 4.15 in (10.54 cm) | |
| Port Replication | Getac Certified Electronics |
| USB 2.0 - 4 Pin (2) Fully powered (1.5 Amps each) | |
| Headphone/Microphone (1 each) | |
| Power Input: 19 Vdc | |
| Antenna: TRI RF (SMA) (optional) |
These Gamber-Johnson docking stations are compatible with the following Getac models:
Getac ZX10 Tablet G1
Getac ZX10 Tablet G2
