Panasonic Toughbook CF-D1 Mk3

The Fully Rugged Diagnostic Tablet

Image of a Panasonic Toughbook CF-D1
CF-D1 Mk3 Models and Prices CF-D1 Accessories CF-D1 Mk3 Specification

The 13.3" widescreen HD IPS display allows field engineers to easily run real-time diagnostic programmes, read telematic data and view schematics and designs. The screen has been specifically built for clarity both inside buildings and outside in bright sunlight, when field engineers are doing pre-diagnostics tests. The resistive touchscreen allows for easy data input using fingers, gloved hands or pens. All of this makes the Toughbook CF-D1 a unique tool. Unique in its ability to transform the way diagnostic engineers work, wherever that might be.

To ensure this new Toughbook Diagnostic Tablet has the power to fulfil its industrial purpose, it uses the six-generation Intel® Core™ Platform and runs the Windows 10 Pro operating system. For convenient use by engineers, the device can be used in a docking cradle with a flexible angle to allow easy viewing in various usage scenarios. The device can also be held with the addition of an optional hand strap or attached to extendable legs, which allow the device to stand alone, alongside the engineer.

  • Intel® Core™ i5-6300U vPro™ Processor
  • Windows 10 Pro
  • Intel® HD graphics 520
  • 13.3" widescreen HD IPS display with Touchscreen
  • Triple modular bay
  • Shock-protected HDD
  • Drop resistant from a height of 90cm*
  • Water / Dust protected according to IP65*
  • Industry specific carrying and docking solutions
  • Up to 12 hours battery Life

* Tested at Panasonic Factory



Image of a Panasonic Toughbook CF-D1 Front Image of a Panasonic Toughbook CF-D1 Back Image of a Panasonic Toughbook CF-D1 Front Left Image of a Panasonic Toughbook CF-D1 Front Right Image of a Panasonic Toughbook CF-D1 Displaying Diagnostics



Panasonic Toughbook CF-D1 Mk3 Models
Model Number Description Price*
CF-D1NW111TE Panasonic Toughbook CF-D1 Mk3 Standard £1999.00
CF-D1NW120TE Panasonic Toughbook CF-D1 Mk3, Dual Pass, 4G £2269.00
CF-D1NW123TE Panasonic Toughbook CF-D1 Mk3, Rear Camera £2074.00
CF-D1NW124TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, GPS £2238.00
CF-D1NW125TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, 4G £2268.00
CF-D1NW126TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, GPS, 4G £2429.00
CF-D1NW127TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, Dual Pass, GPS £2309.00
CF-D1NW128TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, Dual Pass, 4G £2339.00
CF-D1NW129TE Panasonic Toughbook CF-D1 Mk3, Rear Camera, Dual Pass, GPS, 4G £2499.00
CF-D1NW119TE Panasonic Toughbook CF-D1 Mk3, Dual Pass, GPS £2242.00
CF-D1NW121TE Panasonic Toughbook CF-D1 Mk3, Dual Pass, 4G, GPS £2435.00
CF-D1NW117TE Panasonic Toughbook CF-D1 Mk3, 4G £2199.00
CF-D1NW116TE Panasonic Toughbook CF-D1 Mk3, GPS £2170.00
CF-D1NW118TE Panasonic Toughbook CF-D1 Mk3, 4G, GPS £2363.00

To select models with Windows 7, replace the last 2 digits of the model number with CE



Panasonic Toughbook CF-D1 Mk3 Options
Option Price*
256GB SSD £256.00
4GB to 8GB Upgrade £115.00
SmartCard Reader £50.00
VGA (in place of Serial Port) £10.00
Handle and Strap £55.00
Handle, Strap and Put-up-Hinge £105.00



Panasonic Toughbook CF-D1 Extended Warranties
Part Number Description Price*
CF-LESPEW5 Panasonic Toughbook Warranty Extension from 3 to 5 years £129.00
CF-LESPAD3 Panasonic Toughbook Accidental Damage - 3 years contract £145.00
CF-LESPAD5 Panasonic Toughbook Accidental Damage - 5 years (inc. warranty extension) £336.00

*Please note that all prices shown are exclusive of VAT

Leasing the Toughbook CF-D1 is available to organisations and typically costs from £72.81 p/m on a 3-year agreement. For more information see computer leasing.



Alternative Models
Panasonic Toughbook CF-20 Mk1 Panasonic Toughpad FZ-G1 Mk4 Getac V110 G3 Panasonic Toughbook CF-31 Mk5 Getac F110 G3
Image of a Panasonic Toughbook CF-20 Laptop Image of a Panasonic Toughpad FZ-G1 Tablet Image of a Getac V110 Convertible Laptop Image of a Panasonic Toughbook CF-31 Laptop Image of a Getac F110
From £2395.00 From £1730.00 From £1995.00 From £2995.00 From £1560.00

View All Rugged Tablets
View All Panasonic Toughbooks
View All Getacs



Panasonic Toughbook CF-D1 Accessories
Part Number   Description Price*
CF-AA5713AE Image of a Panasonic CF-D1 AC Power Supply CF-AA5713A2E Panasonic Spare Power Supply for CF-D1 £64.39
CF-VZSU73U Image of a Panasonic CF-D1 Li-Ion Battery Pack CF-AA5713A2E Panasonic Lithium Ion Battery Pack for CF-D1 £112.00
CF-VCBTB3W   Panasonic Battery Charger for CF-D1 £132.15
CF-VNP019U Image of a Panasonic Stylus pen for CF-D1 Panasonic Stylus Pen for CF-D1 £9.00
CF-VEBD11U Image of a Panasonic Cradle with DVD Drive for CF-D1 Panasonic Cradle with DVD Multi Drive for CF-D1 £362.00
CF-VEBD11AU Image of a Panasonic Cradle without DVD Drive for CF-D1 Panasonic Cradle without DVD Multi Drive for CF-D1 £338.00
CF-WSTD101 Image of a Panasonic Carry Handle / Strap for Toughbook CF-D1 Panasonic Carry Handle / Strap for CF-D1 £57.12
CF-LND1224A Image of a Lind Car Charger 12V for Toughbook CF-D1 Lind Car Charger (24V) for CF-D1 £133.90
PCPE-LNDAC01   Lind AC/DC Combo Adapter for CF-D1 £154.20
PCPE-RAMD1P1   RAM Mounts Passive Docking Station (No Electronics) for CF-D1 £178.00
PCPE-GJD1V01 Image of a Gamber-Johnson Vehicle Dock for Toughbook CF-D1 Gamber-Johnson Vehicle Dock for CF-D1 £609.00
PCPE-GJD1V02 Image of a Gamber-Johnson Vehicle Dock for Toughbook CF-D1 Gamber-Johnson Vehicle Dock with Antenna Pass-Through for CF-D1 £652.00
PCPE-MMRK01E   Man & Machine So Cool Rugged Keyboard (English) with 3 years warranty £401.35
PCPE-MMRK01F   Man & Machine So Cool Rugged Keyboard (French) with 3 years warranty £401.35
PCPE-MMRK01G   Man & Machine So Cool Rugged Keyboard (German) with 3 years warranty £401.35
CF-WSDD12511   Panasonic 256GB SSD for CF-D1 £319.20
CF-WMBA1304G   Trustin 4GB DIMM (PC3L-12800: DDR3) £83.00
CF-KD1HD5011   Panasonic 500GB Drive for CF-D1 £101.95
PCPE-SYSLD11   Frame with D Ring Corners and Adjustable Shoulder Strap for CF-D1 £79.50
PCPE-SYSLD12   Frame and Double Adjustable Shoulder Strap with Webbing and Shoulder Piece for CF-D1 £83.95
CF-VPF22U   Panasonic LCD Protective Film for CF-D1 400nit £50.50
CF-VPF23U   Panasonic LCD Protective Film for CF-D1 1000nit £58.25

*Please note all prices shown are exclusive of VAT



Panasonic Toughbook CF-D1 Mk3 Full Specification
Mobile Computing Platform Intel® Core™ i5-6300U processor
  (2.4GHz, 3MB Intel® Smart Cache)
Operating System Windows® 10 Professional
  Windows® 7 Professional
RAM 4GB DDR3L SDRAM (max. 16GB)
Graphic Chip Intel® HD graphic 520
Storage 500GB (SATA) HDD
LCD 13.3" Active Matrix colour IPS HD LCD (1366 x 768) with Touchscreen
  Up to 400cd/m² transmissive brightness
Bluetooth™ 4.1 + EDR Class 1
Wireless LAN Intel® Dual Band Wireless-AC 8260
  IEEE 802.11 a/b/g/n/ac compliant
LAN IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE 802.3ab 1000BASE-T (2nd LAN 100MBit optional)
Audio WAVE and MIDI playback, Intel® High Definition Audio subsystem support
Card Slots SD/SDXC Memory card slot x1
Interfaces Serial: Dsub, 9-pin
  VGA: Mini D-sub, 15-pin optional* (eliminates serial)
  LAN: RJ-45, 2nd LAN optional* (Modular Bay Port)
  USB 2.0: x2, 3rd USB 2.0 optional* (Modular Bay Port)
  USB 3.0: x1
  Rugged USB 2.0: x2 optional* (Modular Bay Port / 2nd rugged USB eliminates serial)
  Headphones: Mini-jack, 3.5 DIA, stereo
  Microphone: Mini-jack, 3.5 DIA, stereo
  DC input: Jack
  Industry Cradle: x1
Power AC Adaptor: Input: 100-240V AC, 50Hz/60Hz, Output: 15.6V DC, 7.05A
  Battery: Lithium-Ion (10.8V, 6.2Ah)
  Battery Life: Approx. 12 hours (MobileMark™ 2007, 60cd/m² LCD brightness)
Security Password security (supervisor password, user password, hard disc lock), Kensington Lock, Fingerprint Reader optional, Smartcard Reader optional
Dimensions (W x H x D) 349mm x 46 x 244mm {13.7" x 1.8" x 9.6"}
Weight Approx. 2.25kg {Approx. 4.96lb}
Integrated Options 4G Mobile Broadband (Gobi 5000), GPS, 5MP back camera with LED Flash
Accessories Additional AC Adaptor: CF-AA5713AE/G/T
  Battery Pack: CF-VZSU73U
  Battery Charger: CF-VCBTB3W
  Stylus Pen: CF-VNP019U
  Cradle: CF-VEBD11U (with DVD Multi Drive)
              CF-VEBD11AU
  Display Protection Film: CF-VPF22U
Warranty 3-year warranty covering hardware failures for systems used as designed.

*Project based. Only one interface can be selected.
